X-eye 6000 POP

 X-ray Tube 130 kV / 200 µA
 Min. Resolution 6~15 µm
 Detector 8 M Pixel FPD
 Chip Size Min : 8 x 6 (mm) , Max : 20 x 20 (mm)
 Defects Non-wet, Open, Short, Big / Small ball
 Dimension 2,300(W) x 2,400(D) x 2,120(H)mm / 4,800kg

3D CT X-ray Inspection System for POP(Package on Package)
3D automatic X-ray inspection system for POP(Package on Package), having the latest semiconductor layering technology.
From loading to judgement of NG/Good & sorting out of POP products would be made automatically.
And results would be saved into basic data based to help SPC. It has the fastest inspection speed of 2.5sec/FOV.

  • 3D In-Line inspection system for POP packages
  • Good-NG analysis of interconnection using 3D CT
  • Detection speed : Max. 5 sec/unit

Cu pillar Bump non wet

POP Bump Short
