X-eye 5000N
Detail View →
|
X-ray Tube |
160 kV / 200uA (option 160kV / 500uA) |
|
Min. Resolution |
0.8 um |
|
Table Size |
460 X 510 mm (option 550 X 650 mm) |
|
AXIS |
X,Y,Z, Tilt (70︒), R,Y-aft, Cone Beam R |
|
Detector |
1.6M Pixel FPD |
|
CT scan |
Oblique CT / Cone Beam CT |
|
Dimension |
1,340(W) x 1,950(D) x 1,630(H)mm / 2,000kg |
Best performance X-ray Inspection System
High-performance Micro-focus Open Tube with 160kV is installed and fine defects of 1㎛ are detectable.
High-resolution X-ray image can be gained with world best magnification by installing high-price Open Tube as standard.
Dual CT function can be purchased additionally, and exact location & size of defects can be detected and analyzed with this function.
BGA Cold Solder
Stacked Die
Applications
